ESP32 Dual Core WiFi+Bluetooth Development Board

ESP32 Dual Core WiFi+Bluetooth Development Board - Image 1
ESP32 Dual Core WiFi+Bluetooth Development Board - Image 2
ESP32 Dual Core WiFi+Bluetooth Development Board - Image 3
ESP32 Dual Core WiFi+Bluetooth Development Board
ESP32 Dual Core WiFi+Bluetooth Development Board
ESP32 Dual Core WiFi+Bluetooth Development Board
LKR 1,500.00
LKR 1,750.00
14% OFF
Out of Stock

ESP32 has integrated antenna and RF balun, power amplifier, low-noise amplifiers, filters, and power management module. The entire solution takes up the least amount of printed circuit board area.This board is used with 2.4 GHz dual-mode Wi-Fi and Bluetooth chips by TSMC 40nm low power technology, power and RF properties best, which is safe, reliable, and scalable to a variety of applications.

The ESP32 doesn’t replace the ESP8266, but it does improve on it in every aspect. Not only does it have WiFi support, but it also features a Bluetooth 4.2 radio, making it even more versatile. The CPU is similar to the ESP8266 – it’s a 32-bit Xtensa® LX6, but the ESP32 has two cores! There’s also 128KB of ROM and 416KB SRAM, but Flash memory (for program and data storage) is still left up to an external chip (up to 64MB).


Specifications

Clock Speed
32 kHz crystal oscillator
Features
Integrated dual mode Bluetooth (classic and BLE) Ultra-low noise analog amplifier Hall sensor 10x capacitive touch interface SD-card interface support
Flash Memory
16 MB KB
I/O Pins
Analog-to-Digital Converter (ADC) – Up to 16 channels of 12-bit SAR ADC’s Digital-to-Analog Converter (DAC) – Two 8-bit DAC’s Pulse-Width Modulation (PWM) – Up to 16 channelsTouch Sensor – 10 GPIOs feature capacitive sensing UART – Two UART interfaces I2C, SPI, I2S – There are two I2C and four SPI interfaces
Microcontroller
Tensilica LX6 microcontroller
Operating Voltage
3.3V
Processor
240 MHz dual core
SRAM
520 KB
Temperature Range
-40°C to +125°C operating temperature
WiFi
802.11BGN HT40
