Orange Pi Plus
LKR 8,400.00
View Product Details

It’s an open-source single-board computer. It can run Android 4.4 , Ubuntu, Debian, Rasberry Pi Image, it uses the AllWinner H3 SoC.

Specifications

Audio
3.5 mm Output HDMI MIC
Buttons
Power Button(SW4) Recovery Button(SW2) Uboot Button(SW3)
Communication
10/100/1000M Ethernet RJ45 Realtek RTL8189ETV IEEE 802.11 b/g/n
CPU
H3 Quad-core Cortex-A7 1.6 Supports OpenGL ES 2.0 GHz
GPU
Mali400MP2 GPU @600MHz
Length x Width
108 × 60 mm
Memory
DDR3 (shared with GPU) - 1 GB
Package
Orange Pi Plus Board
Special Features
IR input 40 Pins Header Compatible with Raspberry Pi B+ Power LED Status LED
Storage
TF card (Max. 64GB) / MMC card slot up to 2T on 2.5 SATA disk 8GB EMMC Flash GB
USB
Four USB 2.0 HOST one USB 2.0 OTG
Video Input
A CSI input connector Camera: • Supports 8-bit YUV422 CMOS sensor interface • Supports CCIR656 protocol for NTSC and PAL • Supports SM pixel camera sensor • Supports video capture solution up to 1080p@30fps
Video Output
Supports HDMI output with HDCP Supports HDMI CEC Supports HDMI 30 function Integrated CVBS Supports simultaneous output of HDMI and CVBS
Weight
50 g
