DS1302 DALLAS company launched the trickle charge clock chip contains a real-time clock / calendar and 31 bytes of static RAM, and communicate via a simple serial interface with the microcontroller. The real-time clock / calendar circuit provides seconds, minutes, hours, day, week, month, year, and can automatically adjust the monthly number of days and the number of days of the leap year. Clock operation by the AM / PM indication, the decision to adopt a 24 or 12-hour format. Between the DS1302 and the microcontroller can simply synchronous serial communication only used three lines of: (1) RST Reset (2) I / O data line (3) SCLK Serial Clock. Clock / RAM read / write data to a byte or character groups of up to 31 bytes of communication. DS1302 working when the power consumption is very low to maintain data and clock information when the power is less than 1mW
